100022030 (H02030K0829)
Article number
5043902
Files
Description
Telegaertner SAP nr.: 100022030
Manufacturer partnr.: H02030K0829
EAN.: 4018359542115
Performance Characteristics:
For installation of loose tube cables,
extendable,
Fixed rear panel for secure cable attachement
Remarks: coloured, stripped for splicing
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Number of Adaptors: 12
Colour: aqua
Fiber Pigtails: 24x G50/125, OM3, 1,5 m, LC
Housing Colour: RAL 9005
coupler: color: aqua
Adaptors: LC Duplex, ceramic sleeve, plastic housing
Product package: Housing with cable entries either backwards or sideways, Splice cassette with splice holders for max. 24 fibers and cover, front plate, Adaptors and pigtails see table
Feature & Benefits: Patch panels with pigtails: splice protectors included, Save handling & storaging of fibers and spliced thanks to pre-installed splice cassettes, 242mm: the perfect depth for your rack, Fixation of the rear side cabled via velcroes, cable ties and cable glands, For rear side installation: Max. 3x M20 with optional adapter, Housing: light aluminium, Cable- & fiber storage inside the housing, Comfortable splicing & handling: Pull- & hang-out splicing drawer, Closed housing for improved dust protection, Removable powder coated steel cover included, Datasheet online
Manufacturer partnr.: H02030K0829
EAN.: 4018359542115
Performance Characteristics:
For installation of loose tube cables,
extendable,
Fixed rear panel for secure cable attachement
Remarks: coloured, stripped for splicing
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Number of Adaptors: 12
Colour: aqua
Fiber Pigtails: 24x G50/125, OM3, 1,5 m, LC
Housing Colour: RAL 9005
coupler: color: aqua
Adaptors: LC Duplex, ceramic sleeve, plastic housing
Product package: Housing with cable entries either backwards or sideways, Splice cassette with splice holders for max. 24 fibers and cover, front plate, Adaptors and pigtails see table
Feature & Benefits: Patch panels with pigtails: splice protectors included, Save handling & storaging of fibers and spliced thanks to pre-installed splice cassettes, 242mm: the perfect depth for your rack, Fixation of the rear side cabled via velcroes, cable ties and cable glands, For rear side installation: Max. 3x M20 with optional adapter, Housing: light aluminium, Cable- & fiber storage inside the housing, Comfortable splicing & handling: Pull- & hang-out splicing drawer, Closed housing for improved dust protection, Removable powder coated steel cover included, Datasheet online
