100022091 (H02030N9452)
Article number
5043920
Files
Datasheets
| LWL_OM4_T00013A0316 |
| H02030A9450D |
Brochures
| DataVoice_Office_2016_en |
| DV-Enterprise_Katalog_EN |
Description
Telegaertner SAP nr.: 100022091
Manufacturer partnr.: H02030N9452
EAN.: 4018359553265
Performance Characteristics:
For installation of multifiber cables and TICNET pre-terminated cables
Remarks: for multimode OM4
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Number of Adaptors: 24
coupler: color: violet
Adaptors: LC Duplex, ceramic sleeve, plastic housing, violet
Product package: housing with two cable entries for M20 and M25, 1 cable gland M20 for 5-9mm, 1 cable gland M25 for 9-13mm, 2 dummy plugs for M20 and M25, Splice cassette with integrated splice holders for max. 24 fibers and cover, front plate, Adaptors and pigtails see table, housing with 2 cable entries for M25, 1 dummy plug M25 for 9-13 mm
Feature & Benefits: Patch panels with pigtails: splice protectors included, Save handling & storaging of fibers and spliced thanks to pre-installed splice cassettes, 265mm: the perfect depth for your rack, Fixation of the rear side cabled via velcroes, cable ties and cable glands, For rear side installation: Max. 2x M20 & 2x M25, Housing material: bending resistant powder coated steal, closed housing for improved dust protection, Removable powder coated steel cover included, Datasheet online
