100025477 (J01460A2012)
Article number
5044151
Description
Telegaertner SAP nr.: 100025477
Manufacturer partnr.: J01460A2012
EAN.: 4018359547516
Performance Characteristics:
Space and weight savings due to compact design,
Optimized for 1/4”, 3/8”, 1/2“ corrugated cables,
Very low PIM values independent from torque and coupling mechanism,
Contact areas protected from damage even when not mated,
Screw, Handscrew and Push Pull options with same jack
Remarks: SIMFix Pro, clamp/clamp, IP68
Assembly: B89
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Cable group; cable: G23 (1/2'' Flex)
Type: Hand Screw Type
G23: 5092 1/2"-Hiflex, Flexline 1/2" S, FSJ4-50B, HFSC 12D, HPL 50-1/2SF, RFF 1/2"-50, SCF 12-50 J RFS, Sucofeed 1/2 HF
Manufacturer partnr.: J01460A2012
EAN.: 4018359547516
Performance Characteristics:
Space and weight savings due to compact design,
Optimized for 1/4”, 3/8”, 1/2“ corrugated cables,
Very low PIM values independent from torque and coupling mechanism,
Contact areas protected from damage even when not mated,
Screw, Handscrew and Push Pull options with same jack
Remarks: SIMFix Pro, clamp/clamp, IP68
Assembly: B89
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Cable group; cable: G23 (1/2'' Flex)
Type: Hand Screw Type
G23: 5092 1/2"-Hiflex, Flexline 1/2" S, FSJ4-50B, HFSC 12D, HPL 50-1/2SF, RFF 1/2"-50, SCF 12-50 J RFS, Sucofeed 1/2 HF
