100025485 (J01460A3008)
Article number
5044154
Description
Telegaertner SAP nr.: 100025485
Manufacturer partnr.: J01460A3008
EAN.: 4018359540302
Performance Characteristics:
Space and weight savings due to compact design,
Optimized for 1/4”, 3/8”, 1/2“ corrugated cables,
Very low PIM values independent from torque and coupling mechanism,
Contact areas protected from damage even when not mated,
Screw, Handscrew and Push Pull options with same jack
Remarks: solder/solder IP68
Assembly: A27
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Cable group; cable: G10 (UT-141)
Type: Push Pull Type
G10: 1673A, EZ 141, Flexiform 402, RG-402/U, SUCOFORM 141, UT-141
Manufacturer partnr.: J01460A3008
EAN.: 4018359540302
Performance Characteristics:
Space and weight savings due to compact design,
Optimized for 1/4”, 3/8”, 1/2“ corrugated cables,
Very low PIM values independent from torque and coupling mechanism,
Contact areas protected from damage even when not mated,
Screw, Handscrew and Push Pull options with same jack
Remarks: solder/solder IP68
Assembly: A27
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Cable group; cable: G10 (UT-141)
Type: Push Pull Type
G10: 1673A, EZ 141, Flexiform 402, RG-402/U, SUCOFORM 141, UT-141
