100025488 (J01460A3011)
Article number
5044157
Description
Telegaertner SAP nr.: 100025488
Manufacturer partnr.: J01460A3011
EAN.: 4018359545260
Performance Characteristics:
Space and weight savings due to compact design,
Optimized for 1/4”, 3/8”, 1/2“ corrugated cables,
Very low PIM values independent from torque and coupling mechanism,
Contact areas protected from damage even when not mated,
Screw, Handscrew and Push Pull options with same jack
Remarks: SIMFix, clamp/clamp, IP67
Assembly: E13
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Cable group; cable: G20 (1/4" Flex)
Type: Push Pull Type
G20: 5042 1/4"-Hiflex, FSJ1-50, RFF 1/4"-50, SCF 14-50 J RFS
Manufacturer partnr.: J01460A3011
EAN.: 4018359545260
Performance Characteristics:
Space and weight savings due to compact design,
Optimized for 1/4”, 3/8”, 1/2“ corrugated cables,
Very low PIM values independent from torque and coupling mechanism,
Contact areas protected from damage even when not mated,
Screw, Handscrew and Push Pull options with same jack
Remarks: SIMFix, clamp/clamp, IP67
Assembly: E13
Euroclass: Not relevant
Flaming droplets: Not relevant
Smoke production: Not relevant
Acidity: Not relevant
Cable group; cable: G20 (1/4" Flex)
Type: Push Pull Type
G20: 5042 1/4"-Hiflex, FSJ1-50, RFF 1/4"-50, SCF 14-50 J RFS
Files
Datasheets
100033356ASDT00100E0013 |
2_2_5_Steckverbinder_T00013A0358 |
J01460A3011KP |
Brochures
Koax-Katalog_2021_online |
